E-Catalog > Light Industrial Panel PC > PPC1560-i3-1215U

Features:

• CPU:
  - Intel Core i3-1215U, 2P4E cores, up to 4.40GHz, TDP is 15W
• RAM:
  - DDR4-3200 MHz, 1 x non-ECC SO-DIMM, up to 32GB
• Panel Size: 15.6"
• Resolution: 1366 x 768 or 1920 x 1080
• I/O Port:
  - 6 x USB
  - 2 x COM
  - 2 x LAN
• Expansion:
  - 1 x M.2 Key-M Slot (PCIe x4 NVMe / SATA SSD, 2280) PCIe x4 is default
  - 1 x M.2 Key-E Slot (PCIE + USB 2.0, Support Wifi + BT, 2230)
  - 1 x M.2 Key-B Slot (PCIE + USB 3.0 + USB 2.0, Support 5G/4G, 2242/3052)
  - 1 x SIM Card Wafer
• Display Output:
  - 1 x HDMI
  - 1 x DP++
• Touch Type:
  - True-Flat PCAP Touch or Resistive Touch (Optional)
  - Anti-UV
  - Anti-IR protection
  - Optical Bonding (Optional)
• Working Temp: -20°C ~ 60°C
• OS Support:
  - Windows 10
  - Windows 11
  - Linux
