Product Information :

Name :
PCI-8164
Category :
  1. คอมพิวเตอร์และอุปกรณ์ ซอฟแวร์ ฮาร์ดแวร์
Sub - Category :
  1. Motion Cards
Brand :
Adlink
Model :
PCI-8164
Product Type :
  1. สินค้า, ผลิตภัณฑ์
Short Description :
Advanced 4-axis Servo & Stepper Motion Controllers with High-Speed Triggering

Product Detail :

Features
  • Pulse output rate up to 6.55 MHz
  • Pulse output options: OUT/DIR, CW/CCW
  • 2 - 4 axes linear interpolation
  • 2-axis circular interpolation
  • Multi-axis continuous interpolation
  • Position/Speed change on-the-fly
  • 13 home return modes and auto home search
  • Hardware position compare and trigger with auto-loading FIFO

ADLINK PCI-8164/PXI-8164 is an advanced 4-axis motion controller. Compared with the PCI-8132/34 series, PCI-8164/PXI-8164 offers better linear and circular interpolated move and continuous contouring performance-ideal for advanced pulse train motion control solutions and complicated motion and pick-and-place applications.


 Introduction
  Ordering Information

PCI-8164 Advanced PCI 4-axis Servo & Stepper Motion Controller with High-Speed Triggering
Accessory
DIN-100S-01 Terminal board with one 100-pin SCSI-II connector and DIN-rail mounting
DIN-814M0 Terminal board for Mitsubishi MR-J2S-A servo amplifier
DIN-814M-J3A0 Terminal board for Mitsubishi MR-J3S-A amplifier
DIN-814Y0 Terminal board for Yaskawa Sigma II/III/V amplifiers
DIN-814P-A40 Terminal board for Panasonic MINAS A4 amplifier
DIN-814PA0 Terminal board for Panasonic MINAS A servo amplifier
ACL-102100-1 100-pin SCSI-II cable (mating with AMP-787082-9), 1 M
DIN-814-GP Terminal board for general purpose with 100-pin SCSI-II connector
