E-Catalog > Open Frame Panel PC > OFT-07WR3

PAGE VIEW : 55

Product Information :

Name :
OFT-07WR3
Category :
  1. คอมพิวเตอร์และอุปกรณ์ ซอฟแวร์ ฮาร์ดแวร์
Sub - Category :
  1. Open Frame Panel PC
Brand :
Avalue
Model :
OFT-07WR3
Product Type :
  1. สินค้า, ผลิตภัณฑ์
Short Description :
7" Open Frame Table with Rockchip RK3568J

Product Detail :

Features:

  • CPU: Rockchip RK3568J Quad-core Cortex-A55 1.8GHz
  • RAM: 4GB LPDDR4
  • Panel size: 7"
  • Resolution: 800 x 480
  • I/O Port:
    - 4xUSB
    - 5xCOM
    - 2xLAN
    - 1 x Nano SIM
    - 2 x CAN
    - 1 x DC Input
    - 1 x I2C
    - 1 x M.2 Key B (3042, SATA3 / USB 2.0, support SSD/LTE Module)
    - 1 x RTC Battery
    - 1 x Speaker
    - 1 x Touch Button
  • DIO / GPIO:
    - 1 x 16-bit GPIO by pin wafer
  • Display Output:
    - 1 x HDMI

  • Luminance: 500 cd/m2
  • Touch Type: PCAP
  • Working Temp: -30°C ~ 60°C
  • OS Support:
    - Android 13
    - Debian 11
  • Optional:
    - Optional Wi-Fi 802.11 a/b/g/n/ac/ax
    - Optional BT 5.0
